--- title: "Product Specifications: Lit Fabricated Metal - Face Lit" description: Fabricated metal face lit letters come in two metal materials:  Stainless Steel (Alloy 304) Stainless Steel - titanium coated (Alloy 304) Stainless Steel (Alloy 316) Aluminum (Alloy 5052) Fabricated m --- [Skip to content](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#main-content) English Show submenu for translations ![Gemini Incorporated](https://hub.geminimade.com/hubfs/gemini-logo-horizontal-1.svg) Open main navigation Close main navigation - English Show submenu for translations Try the "Ask me anything" icon at the bottom right to use our AI search - There are no suggestions because the search field is empty. 1. [Gemini Product Guide](https://hub.geminimade.com/knowledge?hsLang=en) 2. [Lit Letters and Logos](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en) 3. [Lit Fabricated Metal Face Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-fabricated-metal-face-lit) September 23, 2026 # Product Specifications: Lit Fabricated Metal - Face Lit | **[Materials](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#Materials)** | **[Size Range](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#MinMaxHeights)** | | --- | --- | | **[Available Depths](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#Depth)** | **[Fonts](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#TypefaceFonts)** | | **[Finishes](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#Finishes)** | **[Paint](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#Paint)** | | **[Install Environment and Cleaning](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#InstallEnvironment)** | **[LED Options](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#LEDoptions)** | | **[Acrylic Inserts](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#AcrylicInserts)** | **[Metal Construction](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#MetalConstruction)** | | **[Mounting](https://hub.geminimade.com/knowledge/fabricated-metal-face-lit-product-specifications#Mounting)** | | ### **Materials** #### Lit Fabricated Metal Face Lit letters and logos are available in two metal materials: Stainless Steel and Aluminum. | ![Brushed2](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Aluminum%20Finishes/Brushed2.jpg?width=100&height=100&name=Brushed2.jpg) | ![Brushed 3](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Fabricated%20Metal/Brushed%203.jpg?width=100&height=100&name=Brushed%203.jpg) | | --- | --- | | **Stainless Steel** • Alloy 304 • Alloy 316 | **Aluminum** • Alloy 5052 |   ![Fabricated Face Lit Comp Final](https://hub.geminimade.com/hs-fs/hubfs/Fabricated%20Face%20Lit%20Comp%20Final.png?width=482&height=271&name=Fabricated%20Face%20Lit%20Comp%20Final.png) **Note:** Vertical grain is standard on all fabricated letters and logos. A horizontal grain can be requested.   --- ### **Size Range** Depending on the metal material and finish, Lit Fabricated Metal Face Lit letters and logos can be made as small as **9"** high up to **60"+** high in a single piece. For exact measurements needed for production, see the **Design Guide** --- ### **Available Depths** | Aluminum | 3" | 3.5" | 4" | 5" | 6" | | --- | --- | --- | --- | --- | --- | | Stainless Steel | 3" | | 4" | 5" | 6" | --- ### **Fonts** Lit Fabricated Metal Face Lit can be made with custom fonts and vector art. We also have over ninety standard fonts if custom artwork is not required. **Tip: [View our standard fonts list here.](https://hub.geminimade.com/knowledge/gemini-standard-fonts?hsLang=en)**  - Letters and fonts - lowercase letters are 10% discounted off of the uppercase letter price. - Punctuation - small punctuation marks, such as commas, periods, or dashes, are 67% discounted off of the uppercase letter price --- ### **Finishes** We offer a variety of standard metal finishes for your made-to-order Face Lit Fabricated Metal sign. Click on either Aluminum or Stainless Steel to learn more. | ![Brushed2](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Aluminum%20Finishes/Brushed2.jpg?width=106&height=106&name=Brushed2.jpg) | ![Brushed2](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Aluminum%20Finishes/Brushed2.jpg?width=106&height=106&name=Brushed2.jpg) | | --- | --- | | [**Stainless Steel Finishes**](https://hub.geminimade.com/knowledge/fabricated-metal-stainless-steel-finishes?hsLang=en) | [**Aluminum Finishes**](https://hub.geminimade.com/knowledge/fabricated-metal-aluminum-finish?hsLang=en) | ### **Paint** We have a selection of **48** [**standard paint colors**](https://hub.geminimade.com/knowledge/standard-paint-colors?hsLang=en) and offer custom paint matching **Tip:** To learn more about our custom paint matching,**[refer to our custom colors article.](https://hub.geminimade.com/knowledge/custom-paint-colors?hsLang=en)**    --- ### **LEDs** Gemini has eight options for LED colors, including programable static RGB. | ![TrimlessFaceLitAlum\_White.160](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_White.160.png?width=670&height=670&name=TrimlessFaceLitAlum_White.160.png) | ![TrimlessFaceLitAlum\_NaturalWhite](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_NaturalWhite.jpg?width=670&height=670&name=TrimlessFaceLitAlum_NaturalWhite.jpg) | ![TrimlessFaceLitAlum\_Warm White.159](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_Warm%20White.159.png?width=670&height=670&name=TrimlessFaceLitAlum_Warm%20White.159.png) | ![TrimlessFaceLitAlum\_Red.158](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_Red.158.png?width=670&height=670&name=TrimlessFaceLitAlum_Red.158.png) | | --- | --- | --- | --- | | Bright White 7000K | Natural White 5000K | Warm White 3000K | Red | | ![TrimlessFaceLitAlum\_Blue.162](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_Blue.162.png?width=670&height=670&name=TrimlessFaceLitAlum_Blue.162.png) | ![TrimlessFaceLitAlum\_Green.161](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_Green.161.png?width=670&height=670&name=TrimlessFaceLitAlum_Green.161.png) | ![TrimlessFaceLitAlum\_Yellow](https://hub.geminimade.com/hs-fs/hubfs/TrimlessFaceLitAlum_Yellow.png?width=670&height=670&name=TrimlessFaceLitAlum_Yellow.png) | ![FacelitFormedPlastic\_RGB](https://hub.geminimade.com/hs-fs/hubfs/FacelitFormedPlastic_RGB.jpg?width=670&height=670&name=FacelitFormedPlastic_RGB.jpg) | | Blue | Green | Yellow | RGB \*Additional charges apply \* Programmable to a Single custom color | \* All Face Lit Fabricated signage is populated with 24V Gemini Brand LEDs.  **Tip:** **Learn about our [LED package](https://5980677.hs-sites.com/knowledge/led-options-and-package?hsLang=en).**   --- ### **Acrylic Inserts** Gemini has seven different acrylic insert options. | ![Stainless-Facelit-white\_dusk-1](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-white_dusk-1.jpg?width=670&height=642&name=Stainless-Facelit-white_dusk-1.jpg) | ![Stainless-Facelit-Ivory\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Ivory_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Ivory_dusk.jpg) | ![Stainless-Facelit-Yellow\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Yellow_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Yellow_dusk.jpg) | ![Stainless-Facelit-Red\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Red_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Red_dusk.jpg) | ![Stainless-Facelit-Purple\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Purple_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Purple_dusk.jpg) | ![Stainless-Facelit-Blue\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Blue_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Blue_dusk.jpg) | ![Stainless-Facelit-Green\_dusk](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Illuminated%20-%20Face%20Lit/Stainless-Facelit-Green_dusk.jpg?width=670&height=642&name=Stainless-Facelit-Green_dusk.jpg) | | --- | --- | --- | --- | --- | --- | --- | | White | Ivory | Yellow | Red | Purple | Blue | Green | **Note:** Acrylic inserts are 3/16 inch thick, vinyl application available – [**contact us through Partner Portal for a quote**](https://geminimade.com/partner/start-quote/) --- ### **Install Environment and Cleaning** Non Lit Fabricated letters and logos are for interior or exterior applications. Exterior installations may require occasional cleaning to maintain original appearance. See our[**Cleaning Guide**](https://hub.geminimade.com/knowledge/letters-and-logos-cleaning-guide?hsLang=en) for more information **Special consideration:** Coastal climates within 50 miles of the ocean should opt for Stainless Steel 316 Alloy or anodized aluminum. These options offer superior corrosion resistance in coastal climates.   --- ### **Metal Construction** #### How are Face Lit Fabricated letters and logos constructed? Fabricated letters are constructed with precision welding, soldering or laser welding in the following specifications.  **Stainless Steel**  | ![FAB\_Removable Face SS-R-DetStud-6000x5400-9c85647](https://hub.geminimade.com/hs-fs/hubfs/FAB_Removable%20Face%20SS-R-DetStud-6000x5400-9c85647.jpg?width=223&height=200&name=FAB_Removable%20Face%20SS-R-DetStud-6000x5400-9c85647.jpg) | - Precision laser welded or soldered - 18 gauge (.0478") or 16 gauge (.0598") thick face - 24 gauge (.0239") thick return | | --- | --- |   **Aluminum Letters** | ![AlumFabBack](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Fabricated%20Metal/AlumFabBack.jpg?width=145&height=180&name=AlumFabBack.jpg) | - Precision laser or MIG welded - .090-inch face in all sizes - .063-inch returns for all sizes (return grain will run from face to back) | | --- | --- | --- ### **Mounting** We have several mounting options for Face Lit Fabricated letters and logos.  **Note:** All orders come with standard mounting and pattern for installation. | ![Screenshot 2026-08-26 145232](https://hub.geminimade.com/hs-fs/hubfs/Screenshot%202026-08-26%20145232.png?width=120&height=154&name=Screenshot%202026-08-26%20145232.png) | **Stud Mount** - Alignment for rails, bricks, and blocks available - Add spacers to give a stand off look | | --- | --- | | ![Screenshot 2026-08-26 145352](https://hub.geminimade.com/hs-fs/hubfs/Screenshot%202026-08-26%20145352.png?width=137&height=165&name=Screenshot%202026-08-26%20145352.png) | **Detachable Stud** - Up to 24" - Has a 1.5" standoff - Use Allen wrench to easy disconnect letter or logo from wall | | ![Screenshot 2026-08-26 145613](https://hub.geminimade.com/hs-fs/hubfs/Screenshot%202026-08-26%20145613.png?width=126&height=170&name=Screenshot%202026-08-26%20145613.png) | **Bottom or Top Stud/Rail** - Sizes (12" - 48") - +35% cost - Optional rails types include C-Channel or Angle. +50% cost | | ![LetterG\_TrimlessChannel\_Raceway\_Backside](https://hub.geminimade.com/hs-fs/hubfs/LetterG_TrimlessChannel_Raceway_Backside.png?width=218&height=123&name=LetterG_TrimlessChannel_Raceway_Backside.png) | **Raceway** - Sizes (12" - 60") - Sizes over 32" require multiple raceways - Raceways made from 24" to 96" in length and 2" to 5" in height - Additional charge depending on size of raceway | | ![Mount\_DoubleRail](https://hub.geminimade.com/hs-fs/hubfs/Gemini%20Guide%20Images/Fabricated%20Metal/Mount_DoubleRail.jpg?width=139&height=150&name=Mount_DoubleRail.jpg) | **Rail Mount** - Single or Double Rail - C-Channel, Angle Bracket or Flat Rail(s) - Single can have sizes (8" - 24"), + 25% cost - Double can have sizes (8" - 36"), + 40% cost - Rails are either painted or anodized aluminum | #### More About Face Lit Fabricated  Letters and Logos --- [**Product Overview**](https://5980677.hs-sites.com/knowledge/fabricated-metal-face-lit-overview?hsLang=en) **[Project Examples](https://5980677.hs-sites.com/knowledge/fabricated-metal-face-lit-project-examples?hsLang=en)** [**Design Guide: Fabricated Stainless Steel Face Lit**](https://hub.geminimade.com/knowledge/design-guide-fabricated-stainless-steel-face-lit?hsLang=en) [**Design Guide: Fabricated Aluminum Face Lit**](https://hub.geminimade.com/knowledge/design-guide-fabricated-aluminum-face-lit?hsLang=en) - [Quote and Order Lead Times](https://hub.geminimade.com/knowledge/quote-and-order-lead-times?hsLang=en) - [Partner Portal "How-To" Articles](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#main-content) - [FAQs](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#faqs) - [General](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#general) - [Artwork](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#artwork) - [Quoting/Ordering](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#quoting-ordering) - [Help & Support Messaging](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#help-support-messaging) - [Shipping](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#shipping) - [Account Management](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#account-management) - [Usability and Accessibility](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#usability-and-accessibility) - [Gemini Sign Assistant](https://hub.geminimade.com/knowledge/partner-portal-how-to-articles?hsLang=en#gemini-sign-assistant) - [Partner Resources](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#main-content) - [Partner General Resources](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#partner-general-resources) - [Partner Portal Release Notes](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#partner-portal-release-notes) - [International Partners](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#international-partners) - [Partner News](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#partner-news) - [Webinars](https://hub.geminimade.com/knowledge/partner-resources?hsLang=en#webinars) - [Plastic Letters and Logos](https://hub.geminimade.com/knowledge/plastic-letters-and-logos?hsLang=en#main-content) - [Flat Cut Acrylic](https://hub.geminimade.com/knowledge/plastic-letters-and-logos?hsLang=en#flat-cut-acrylic) - [Flat Cut PVC](https://hub.geminimade.com/knowledge/plastic-letters-and-logos?hsLang=en#flat-cut-pvc) - [Formed Plastic](https://hub.geminimade.com/knowledge/plastic-letters-and-logos?hsLang=en#formed-plastic) - [Metal Letters and Logos](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#main-content) - [Flat Cut Metal](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#flat-cut-metal) - [Cast Metal](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#cast-metal) - [Fabricated Metal](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#fabricated-metal) - [Blade Signs Non-Lit](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#blade-signs-non-lit) - [Metal Finishes](https://hub.geminimade.com/knowledge/metal-letters-and-logos?hsLang=en#metal-finishes) - [Laminate Letters and Logos](https://hub.geminimade.com/knowledge/laminate-letters-and-logos?hsLang=en#main-content) - [GemLeaf](https://hub.geminimade.com/knowledge/laminate-letters-and-logos?hsLang=en#gemleaf) - [Metal Laminate on Acrylic](https://hub.geminimade.com/knowledge/laminate-letters-and-logos?hsLang=en#metal-laminate-on-acrylic) - [Laminate on Foam](https://hub.geminimade.com/knowledge/laminate-letters-and-logos?hsLang=en#laminate-on-foam) - [Lit Letters and Logos](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#main-content) - [Lit Fabricated Metal Halo Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-fabricated-metal-halo-lit) - [Lit Fabricated Metal Face Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-fabricated-metal-face-lit) - [Blade Signs](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#blade-signs) - [Lit Cast Metal](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-cast-metal) - [Trimless Fabricated Metal Halo Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#trimless-fabricated-metal-halo-lit) - [Trimless Fabricated Metal Face Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#trimless-fabricated-metal-face-lit) - [Trimless Channel Face Lit](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#trimless-channel-face-lit) - [Lit Formed Plastic](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-formed-plastic) - [Lit Acrylic Face Lit (L-100)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-face-lit-l-100) - [Lit Acrylic Face and Halo Lit (L-200)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-face-and-halo-lit-l-200) - [Lit Acrylic Face and Side Lit (L-300)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-face-and-side-lit-l-300) - [Lit Acrylic Metal Face Side Lit (L-400)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-metal-face-side-lit-l-400) - [Lit Acrylic Side Lit (L-500)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-side-lit-l-500) - [Lit Acrylic Translucent Vinyl Face And Side Lit (L-600)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-translucent-vinyl-face-and-side-lit-l-600) - [Lit Acrylic Translucent Vinyl Face Lit (L-700)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-translucent-vinyl-face-lit-l-700) - [Lit Acrylic Translucent Vinyl Face And Halo Lit (L-800)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-translucent-vinyl-face-and-halo-lit-l-800) - [Trimless Lit Acrylic Halo Lit (L-900)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#trimless-lit-acrylic-halo-lit-l-900) - [Lit Acrylic Halo Lit (L-1000)](https://hub.geminimade.com/knowledge/lit-letters-and-logos?hsLang=en#lit-acrylic-halo-lit-l-1000) - [Plaques](https://hub.geminimade.com/knowledge/plaques?hsLang=en#main-content) - [Precision Plaques](https://hub.geminimade.com/knowledge/plaques?hsLang=en#precision-plaques) - [Cast Plaques](https://hub.geminimade.com/knowledge/plaques?hsLang=en#cast-plaques) - [Etched Plaques](https://hub.geminimade.com/knowledge/plaques?hsLang=en#etched-plaques) - [Bronze Memorials](https://hub.geminimade.com/knowledge/plaques?hsLang=en#bronze-memorials) - [Raised Print](https://hub.geminimade.com/knowledge/plaques?hsLang=en#raised-print) - [Thin Gauge Metal Signs](https://hub.geminimade.com/knowledge/thin-gauge-metal-signs?hsLang=en#main-content) - [Thin Gauge Metal Signs](https://hub.geminimade.com/knowledge/thin-gauge-metal-signs?hsLang=en#thin-gauge-metal-signs) - [Printed Dimensional Signage](https://hub.geminimade.com/knowledge/printed-dimensional-signage?hsLang=en) - [More Resources](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#main-content) - [Fonts](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#fonts) - [Paint](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#paint) - [Mounting and Installation](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#mounting-and-installation) - [Shipping](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#shipping) - [Cleaning and Maintenance](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#cleaning-and-maintenance) - [Warranty](https://hub.geminimade.com/knowledge/more-resources?hsLang=en#warranty) - [Search](https://hub.geminimade.com/knowledge/search?hsLang=en) [![Gemini Incorporated](https://hub.geminimade.com/hubfs/gemini-logo-horizontal-1.svg "Gemini Incorporated")](https://geminimade.com/signage/) Gemini, Inc. Help Center Copyright © 2026, Gemini Inc. ![AI Star](https://hub.geminimade.com/hubfs/Web%20Assets/breeze-star.svg) Ask me anything… ![Send](https://hub.geminimade.com/hubfs/Web%20Assets/breeze-send.svg)
